WesAudio Prometheus

Manufacturer: WesAudio

Be the first to review this product

Product ID: wesaudio_prometheus

~~$1,798.80~~
$1,499.00

Add to wish list E-mail to a friend

Overview

WesAudio Prometheus 500 series analog passive dual channel Equalizer with digital recall.

WesAudio Prometheus
500 series analog passive dual channel
Equalizer with Digital Recall.

_PROMETHEUS is fully analog passive EQ with +24dBu of headroom. It features pultec-style warm sound with a lot of innovative improvements. Its modern approach to design allows instant recall of your classic vibe through very flexible plugin available in most common formats. _PROMETHEUS as all ng500 products, integrates with your DAW environment via front panel USB socket or _TITAN chassis.

FEATURES

+24dBu of headroom
Stereo / Dual mono / Mid/Side operation mode
Passive equalizer (Pultec-style) design based on inductors
Analog inductor
Proprietary THD implementation
Flexible DAW/Live plug-in control for instant recall
6 touch sensitive encoders allows to record automation
True bypass
In and OUT metering with clip detection
A/B compare feature
Low frequency boost/cut – 20, 30, 60, 100, 120, 250 Hz.
High frequency boost – 2, 3, 4, 5, 8, 10, 12, 16 kHz.
High frequency cut – 4, 8, 12, 20 KHZ.

SPECIFICATIONS

Frequency response	10Hz-150kHz (-2dB)
THD+N < 0.01%	(1kHz,0dBu)
Input impedance	10kohm
Output impedance	< 100ohm
Max signal level	+24dBu
Crosstalk	< -100dB
THD (MID switch)	1%
THD (HIGH switch)	2.5%
Power consumption	70mA per rail
Dimensions	76x133x158mm
Warranty	2 years
