  • Audient ASP4816 - Compact Analogue Recording Console
Click to enlarge
Price: $18,999.00
Product ID : ASP4816
Manufacturer: Audient
E-mail to a friend | Add To Wish List

Purchase

non-cancelable and non-returnable

Description

Audient ASP4816 Compact Analogue Recording Console


SPECIAL ORDER ITEM: non-cancelable and non-returnable

The Audient ASP4816 provides the key features of a large format recording in a compact - cost effective format. Designed by audio guru David Dearden and featuring Audient?s legendary analog circuitry - ASP4816 is the perfect centre piece for production studios and educational facilities.


Features:

  • In-line architecture - twin inputs on each channel
  • 40 faders
  • 48 inputs at mix
  • 16 Audient Class-A mic pres
  • 16 channels of EQ
  • 16 record buses
  • 6 auxes, 2 cue sends
  • Stereo bus compressor
  • Comprehensive monitor section



Specifications:

Frequency Response
Mic input to Mix output <+0,-0.3dB 20Hz-20kHz @6-40dB gain.
Line input to Mix output <+0,-0.3dB 20Hz-20kHz @0dB gain.


    THD AND NOISE AT +20dB OUTPUT

    Mic XLR input to any output <0.005% at 1kHz
    Line input to any output <0.005% at 1kHz
    Tape input to any output < 0.003% at 1kHz


    NOISE

    Mic EIN (20-20kHz, 150R source) <-127.5dBu
    Bus noise (no inputs routed) <-93dBu
    Bus noise (36 inputs routed) <-78dBu


    CROSSTALK AND MUTE ATTENUATION AT 1kHz

    Short fader Mute >90dB Long fader Mute >90dB Mix assign >90dB Bus assign >90Db


    MIC CMRR

    70dB (Min gain)
    75dB (Max gain)


    MAXIMUM INPUT

    Mic >+21dBu (min gain)
    Line +30dBu (min gain)
    insert return >+21dBu


    MAXIMUM OUTPUT INTO 2K OHMS

    Mix output >+26dBu
    Bus output >+26dBu
    Aux output >+26dBu
    Insert send >+20dBu
    Monitor, Studio, F/B outputs >+20dBu
